JungheinrichEKX 514a / 516ka / 516a
Our high-performance and modular EKXa impresses as a Mobile Robot, developed on the basis of our proven electric order picker/trilateral stacker EKX. The EKXa is distinguished by maximum performance at lift heights of up to 13,000 mm and sets benchmarks in automated narrow-aisle warehousing.
Overview
Equipped with an 80-volt drive and a maintenance-free synchronous reluctance motor, it reaches entirely new performance dimensions while simultaneously reducing energy consumption. With the optional integration of an on-board charger as well as a conductor rail and current collector, it is ideally equipped for 24/7 operation. The optional 360° safety sensor system enables the use of the EKXa in an open, non-fenced narrow-aisle warehouse. With the optional pallet and empty-space detection feature, existing racking in previously manually operated narrow-aisle warehouses can be automated. Thanks to field-proven inductive guidance in combination with RFID transponders, precise positioning at the storage location as well as automatic aisle changes become possible. With the option of step-by-step automation, all paths to warehouse processes with maximum availability, efficiency and performance are open to you.
Screenshots & videos
Key facts
Features
- Use case
- High lift
- Battery technology
- Lead-acid batteries, Lithium-ion batteries (Li-Ion)
- Industry
- Automotive, E-Commerce, Retail, Food, Parcel logistics, Pharma, Production, Returns, Textiles and fashion
- Communication protocols
- CAN-Bus, EtherCAT, HTTP/HTTPS
- Charging options
- Charging via sliding contacts
- Humidity
- Dry
- Market segment
- Enterprise, Small business, Mid-market
- Possible handover points
- Conveyor system closed, Conveyor system open, Rack
- Navigation technology
- Inductive guidance, RFID tags
- Temperature range
- Ambient (+14 °C to +21 °C), Fresh (+4 °C to +7 °C), Ultra-fresh (0 °C to +4 °C)
Soft Facts
- Soft Facts
- 24/7 Support, CE Certification, Direct Sales, Partner Sales, Standalone
Payment models
- Pricing model
- One-time payment, Leasing
Features
- Noise level
- 65 db
- Load capacity
- 1600 Kilogramm
How users rate EKX 514a / 516ka / 516a
100 % of reviewers would recommend this solution (counts reviews that scored the recommendation question 4 or 5 out of 5; 1 to 3 counts as no recommendation).
How we calculate the even Score
The even Score (0 to 100) sets the order of solutions. It is based only on published reviews:
- 85% quality: the average of performance, reliability and maintenance effort per review.
- Recency: newer reviews count more. After one year, a review counts only half as much.
- Smoothing: with few reviews, the value is pulled towards the category average. A single review cannot push a solution to the very top or bottom.
- 15% recommendation: how many reviewers would recommend the solution (NPS logic).
None of this can be bought: plans, advertising and partnerships play no part.
What users say about EKX 514a / 516ka / 516a
The Solution EKX 514a / 516ka / 516a receives an overall Review score of 4.7/5, which is above the category average of 4.5/5. In the areas of performance and reliability, it achieves the maximum scores of 5/5, in line with the category average. Maintenance effort is rated 4/5, which is below the average of 4.8/5. The NPS score of 100 indicates a high level of customer satisfaction. The Reviews emphasize the reliability, ease of use and strong performance of the units, particularly in the areas of carton picking and full pallet movements. Challenges were rarely mentioned, and the reviewer expresses a positive view of the modern features the Solution offers.
All reviews1
„A Classic“
I have been working with EKX devices for over 10 years, implementing carton picking operations as well as full pallet movements.
The EKX are legendary among narrow-aisle machines — and not without good reason.
The EKX range has delivered reliable, mature, and user-friendly devices for decades. Performance is excellent and handling is effortlessly simple. Acceptance within my teams has always been very high.
The devices have continuously evolved; reliability has never been an issue. Wear and maintenance costs have also been low.
With warehouse navigation and vehicle automation, all the features I wished for in the past are now available.
